Downloading latest version of utPLSQL

To download latest version of utPLSQL from github on both Unix/Linux as well as Windows machines use the below smippets.


# Get the url to latest release "zip" file
UTPLSQL_DOWNLOAD_URL=$(curl --silent | awk '/browser_download_url/ { print $2 }' | grep ".zip" | sed 's/"//g')
# Download the latest release "zip" file
# Extract downloaded "zip" file
unzip -q

You may download with a one-liner if that is more convenient.

curl -LOk $(curl --silent | awk '/browser_download_url/ { print $2 }' | grep ".zip" | sed 's/"//g')


To run the script on windows you will need PowerShell 3.0 or above. You will also need .NET 4.0 Framework or above.

$archiveName = ''
$latestRepo = Invoke-WebRequest
$repo = $latestRepo.Content | Convertfrom-Json

$urlList = $repo.assets.browser_download_url

Add-Type -assembly ""

foreach ($i in $urlList) {

   $fileName = $i.substring($i.LastIndexOf("/") + 1)

   if ( $fileName.substring($fileName.LastIndexOf(".") + 1) -eq 'zip' ) {
      Invoke-WebRequest $i -OutFile $archiveName
      $fileLocation = Get-ChildItem | where {$_.Name -eq $archiveName}

      if ($fileLocation) {

Headless installation

To install the utPLSQL into a new database schema and grant it to public, execute the script install_headless.sql as SYSDBA.

The script accepts three optional parameters that define:

  • username to create as owner of utPLSQL (default ut3)
  • password for owner of utPLSQL (default XNtxj8eEgA6X6b6f)
  • tablespace to use for storage of profiler data (default users)

Example invocation of the script from command line:

cd source
sqlplus sys/sys_pass@db as sysdba @install_headless.sql

Invoking script with parameters:

cd source
sqlplus sys/sys_pass@db as sysdba @install_headless.sql utp3 my_verySecret_password utp3_tablespace

The script needs to be executed by SYSDBA, in order to grant access to DBMS_LOCK and DBMS_CRYPTO system packages.

Recommended Schema

It is highly recommended to install utPLSQL in it’s own schema. You are free to choose any name for this schema. Installing uPLSQL into shared schema is really not recommended as you loose isolation of framework.

If the installation and utPLSQL owner user is one and the same, the user must have the following Oracle system permissions before you can proceed with the installation.


In addition the user must be granted the execute privilege on DBMS_LOCK and DBMS_CRYPTO packages.

utPLSQL is using DBMS_PROFILER tables for code coverage. The tables required by DBMS_PROFILER will be created in the installation schema unless they already exist. The uninstall process will not drop profiler tables, as they can potentially be shared and reused for profiling PLSQL code.

It is up to DBA to maintain the storage of the profiler tables.

Manual installation procedure

Creating schema for utPLSQL

To create the utPLSQL schema and grant all the required privileges execute script create_utplsql_owner.sql from the source directory with parameters:

  • user name - the name of the user that will own of utPLSQL object
  • password - the password to be set for that user
  • tablespace name - the tablespace name to hold data created during test execution

Example invocation:

cd source
sqlplus sys/sys_password@database as sysdba @create_utPLSQL_owner.sql ut3 ut3 users

Installing utPLSQL

To install the utPLSQL framework into your database run the /source/install.sql script and provide schema_name where utPLSQL is to be installed.
Schema must be created prior to calling the install script. You may install utPLSQL from any account that has sufficient privileges to create objects in other users schema.

Example invocation:

cd source
sqlplus admin/admins_password@database @install.sql ut3

Allowing other users to access the utPLSQL framework

In order to allow other users to access utPLSQL, synonyms must be created and privileges granted. You have two options:

  • use grants and synonyms to public, to allow all users to access the framework
  • use synonyms and grants for individual users to limit the access to the framework

To grant utPLSQL to public execute script source/create_synonyms_and_grants_for_public.sql and provide schema_name where utPLSQL is installed.

Example invocation:

cd source
sqlplus admin/admins_password@database @create_synonyms_and_grants_for_public.sql ut3

To grant utPLSQL to an individual user, execute scripts source/create_user_grants.sql and source/create_user_synonyms.sql, provide schema_name where utPLSQL is installed and user_name to grant access for.

Example invocation:

cd source
sqlplus ut3_user/ut3_password@database @create_user_grants.sql ut3 hr
sqlplus user/user_password@database @create_user_synonyms.sql ut3 hr

The following tools that support the SQL*Plus commands can be used to run the installation script:

Additional requirements

In order to use the Code Coverage functionality of utPLSQL, users executing the tests must have the CREATE privilege on the PLSQL code that the coverage is gathered on. This is a requirement of DBMS_PROFILER package.

In practice, user running tests for PLSQL code that he does not own, needs to have CREATE ANY PROCEDURE/CREATE ANY TRIGGER privileges. Running code coverage on objects that the user does not own will not produce any coverage information without those privileges.

Uninstalling utPLSQL

To uninstall run uninstall.sql and provide schema_name where utPLSQL is installed.

Example invocation:

cd source
sqlplus admin/admins_password@database @uninstall.sql ut3

The uninstall script will remove all the objects installed by the install script. Additionally, all the public and private synonyms pointing to the objects in the utPLSQL schema will be removed.

If you have extended any utPLSQL types such as a custom reporter, these will need to be dropped before the uninstall, otherwise the uninstall script might fail.

The uninstall script does not drop the schema.

In order for the uninstall to be successful, you need to use the uninstall script that was provided with the exact utPLSQL version installed on your database. i.e. the uninstall script provided with version 3.0.1 will probably not work if you want to remove version 3.0.0 from your database.

Version upgrade

Currently, the only way to upgrade version of utPLSQL v3.0.0 and above is to remove the previous version and install the new version.

Working with utPLSQL v2

If you are using utPLSQL v2, you can still install utPLSQL v3. The only requirement is that utPLSQL v3 needs to be installed in a different schema than utPLSQL v2.

utPLSQL v3 and utPLSQL v2 do not collide on public synonym names.
